YASKAWA A1000 Series Technical Manual

B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 411
Parameter List
B
◆ d: References
Reference parameters are used to set the various frequency reference values during operation.
■
d1: Frequency Reference
No.(Addr.) Name Description Setting Page
d1-01
(280H)
<20> Range upper limit is determined by the maximum output frequency (E1-04) and the upper limit of the frequency reference (d2-01).
<26> The setting range is 0.0 to 66.0 in AOLV/PM.
Frequency Reference 1
Sets the frequency reference for the drive. Setting units are determined by parameter o1-03.
Default: 0.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<20> <26>
180
d1-02
(281H)
Frequency Reference 2 180
d1-03
(282H)
Frequency Reference 3 180
d1-04
(283H)
Frequency Reference 4 180
d1-05
(284H)
Frequency Reference 5 180
d1-06
(285H)
Frequency Reference 6 180
d1-07
(286H)
Frequency Reference 7 180
d1-08
(287H)
Frequency Reference 8 180
d1-09
(288H)
Frequency Reference 9 180
d1-10
(28BH)
Frequency Reference 10 180
d1-11
(28CH)
Frequency Reference 11 180
d1-12
(28DH)
Frequency Reference 12 180
d1-13
(28EH)
Frequency Reference 13 180
d1-14
(28FH)
Frequency Reference 14 180
d1-15
(290H)
Frequency Reference 15 180
d1-16
(291H)
Frequency Reference 16 180
d1-17
(292H)
Jog Frequency Reference
Sets the jog frequency reference. Setting units are determined by parameter o1-03.
Default: 6.00 Hz
Min: 0.00 Hz
Max: 400.00 Hz
<20> <26>
180
All Modes
common_
TMonly
All Modes
common_
TMonly

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
