B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 401
Parameter List
B
b: Application
Application parameters configure the source of the Run command, DC Injection Braking, Speed Search, timer functions,
PID control, the Dwell function, Energy Savings, and a variety of other application-related settings.
b1: Operation Mode Selection
No.(Addr.) Name Description Setting Page
b1-01
(180H)
<11> Setting 2 and 3 are not available when using CLV.
Frequency Reference Selection 1
0: Digital operator
1: Analog input terminals
2: MEMOBUS/Modbus communications
3: Option PCB
4: Pulse input (terminal RP)
Default: 1
Min: 0
Max: 4
136
b1-02
(181H)
Run Command Selection 1
0: Digital operator
1: Digital input terminals
2: MEMOBUS/Modbus communications
3: Option PCB
Default: 1
Min: 0
Max: 3
137
b1-03
(182H)
Stopping Method Selection
0: Ramp to stop
1: Coast to stop
2: DC Injection Braking to stop
3: Coast with timer
9: Simple Positioning
Default: 0
Min: 0
Max: 9
<11>
138
b1-04
(183H)
Reverse Operation Selection
0: Reverse enabled.
1: Reverse disabled.
Default: 0
Min: 0
Max: 1
140
b1-05
(184H)
Action Selection below Minimum
Output Frequency
0: Operates according to frequency reference (E1-09 is disabled).
1: Output shuts off (coast to stop if less than E1-09).
2: Operates according to E1-09 (frequency reference set to E1-09).
3: Zero speed (frequency reference becomes zero when less than E1-09).
Default: 0
Min: 0
Max: 3
140
b1-06
(185H)
Digital Input Reading 0: Input status is read once and processed immediately (for quick response)
1: Input is read twice and processed only if the status is the same in both readings (robust
against noisy signals)
Default: 1
Min: 0
Max: 1
142
b1-07
(186H)
LOCAL/REMOTE Run Selection
0: An external Run command has to be cycled at the new source to be activated.
1: An external Run command at new source is accepted immediately.
Default: 0
Min: 0
Max: 1
142
b1-08
(187H)
Run Command Selection while in
Programming Mode
0: Run command not accepted while in the Programming Mode.
1: Run command accepted while in the Programming Mode.
2: Prohibit entering Programming Mode during run.
Default: 0
Min: 0
Max: 2
143
b1-14
(1C3H)
Phase Order Selection
0: Standard
1: Switch phase order (reverses the direction of the motor)
Default: 0
Min: 0
Max: 1
143
b1-15
(1C4H)
Frequency Reference Selection 2
Enabled when an input terminal set for “External reference” (H1- = 2) closes.
0: Digital operator
1: Terminals (analog input terminals)
2: MEMOBUS/Modbus communications
3: Option card
4: Pulse train input
Default: 0
Min: 0
Max: 4
143
b1-16
(1C5H)
Run Command Selection 2
Enabled when a terminal set for “External reference” (H1- = 2) closes.
0: Digital operator
1: Digital input terminals
2: MEMOBUS/Modbus communications
3: Option card
Default: 0
Min: 0
Max: 3
143
b1-17
(1C6H)
Run Command at Power Up
0: Disregarded. A new Run command needs to be issued after power up.
1: Allowed. Motor will start immediately after power up if a Run command is already enabled.
Default: 0
Min: 0
Max: 1
143
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
