B.4 Control Mode Dependent Parameter Default Values
B.4 Control Mode Dependent Parameter Default Values
The tables below list parameters that depend on the control mode selection (A1-02 for motor 1, E3-01 for motor 2).
These parameters are initialized to the shown values if the control mode is changed.
◆ A1-02 (Motor 1 Control Mode) Dependent Parameters
Table B.2 A1-02 (Motor 1 Control Mode) Dependent Parameters and Default Values
No. Name Setting Range Resolution
Control Modes (A1-02)
V/f (0) V/f w/PG (1) OLV (2) CLV (3)
b2-01 DC Injection Braking Start Frequency 0.0 to 10.0 0.1 0.5 Hz 0.5 Hz 0.5 Hz 0.5 Hz
b2-04
<9> Default setting is determined by the drive model (o2-04) and duty selection (C6-01).
DC Injection Braking Time at Stop 0.00 to 10.00 0.01 s 0.50 0.50 0.50 0.50
b3-01Speed Search Selection at Start 0 to 1 – 0101
b3-02 Speed Search Deactivation Current 0 to 200 1% 120 – 100 –
b3-14Bi-Directional Speed Search Selection 0 to 1 1 1011
b8-01Energy Saving Control Selection 0 to 1 – 0000
b8-02 Energy Saving Gain 0.0 to 10.0 0.1 – – 0.7 1.0
b8-03 Energy Saving Control Filter Time Constant 0.00 to 10.00 0.01 s – –
0.50,
2.00
(Motor
Capacity:
55 kW and
above)
0.01,
0.05
(Motor
Capacity:
55 kW and
above)
C2-01 S-Curve Time at Acceleration Start 0.00 to 10.00 0.01 s 0.20 0.20 0.20 0.20
C3-01 Slip Compensation Gain 0.0 to 2.5 0.1 0.0 – 1.0 1.0
C3-02 Slip Compensation Primary Delay Time 0 to 10000 1 ms 2000 – 200 –
C4-01 Torque Compensation Gain 0.00 to 2.50 0.01 1.00 1.00 1.00 –
C4-02 Torque Compensation Primary Delay Time 0 to 10000 1 ms 200 200 20 –
C5-01 ASR Proportional Gain 1 0.00 to 300.00 0.01 – 0.20 – 20.00
C5-02 ASR Integral Time 1 0.000 to 10.000 0.001 s – 0.200 – 0.500
C5-03 ASR Proportional Gain 2 0.00 to 300.00 0.01 – 0.02 – 20.00
C5-04 ASR Integral Time 2 0.000 to 10.000 0.001 s – 0.050 – 0.500
C5-06 ASR Primary Delay Time Constant 0.000 to 0.500 0.001 s – – – 0.004
C6-02 Carrier Frequency Selection 1 to F – 7 <9> 7 <9> 7 <9> 7 <9>
E1-04 to
E1-10
The default setting of these parameters depends on the control mode but also on the drive capacity. Refer to V/f Pattern Default Values on page 456.
F1-05PG 1 Rotation Selection 0 to 1 – 0000
F1-09 Overspeed Detection Delay Time 0.0 to 2.0 0.1 s – 1.0 – 0.0
L1-01Motor Overload Protection Selection 0 to 4 – 1111
L3-20 DC Bus Voltage Adjustment Gain 0.00 to 5.00 0.01 1.00 1.00 0.30 0.30
L3-21 Accel/Decel Rate Calculation Gain 0.00 to 10.00 0.01 1.00 1.00 1.00 1.00
L4-02 Speed Agreement Detection Width 0.0 to 20.0 0.1 2.0 Hz 2.0 Hz 2.0 Hz 2.0 Hz
L4-04 Speed Agreement Detection Width (+/–) 0.0 to 20.0 0.1 2.0 Hz 2.0 Hz 2.0 Hz 2.0 Hz
L8-38 Carrier Frequency Reduction Selection 0 to 2 1 <9> <9> <9> <9>
L8-40 Carrier Frequency Reduction Off Delay Time 0.00 to 2.00 0.01 s 0.50 0.50 0.50 0.50
o1-03Digital Operator Display Selection 0 to 3 1 0000
o1-04V/f Pattern Display Unit 0 to 1 1 –––0

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
