7.4 Cooling Fan and Circulation Fan
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 351
Periodic Inspection &
Maintenance
7
7.4 Cooling Fan and Circulation Fan
NOTICE: Follow cooling fan replacement instructions. The cooling fan cannot operate properly when installed incorrectly and could
seriously damage the drive. To ensure maximum useful product life, replace all cooling fans when performing maintenance.
Contact your Yaskawa representative or the nearest Yaskawa sales office to order replacement cooling fans as required.
For drives with multiple cooling fans, replace all the fans when performing maintenance to ensure maximum product
performance life.
Number of Fan
Three-Phase 200 V Class Three-Phase 400 V Class
Model
CIMR-A
Cooling Fan Circulation Fan Page
Model
CIMR-A
Cooling Fan Circulation Fan
Control Board
Cooling Fan
Page
2A0004 4A0002
2A0006 4A0004
2A0010 4A0005
2A0012 4A0007 1
353
2A0021 1
353
4A0009 1
2A0030 2 4A0011 1
2A0040 2 4A0018 2
2A0056 2 4A0023 2
2A0069 2 4A0031 2
2A0081 2 4A0038 2
2A0110 2
355
4A0044 2
2A0138 2 4A0058 2
355
2A0169 2
359
4A0072 2
2A0211 2 4A0088 2
357
2A0250 2 4A0103 2
2A0312 2 4A0139 2
359
2A0360 3 1 4A0165 2
2A0415 3 1 4A0208 2
4A0250 3
4A0296 3
4A0362 3 1
4A0414 3 1 363
4A0515 3 2 2
365
4A0675 3 2 2
