B.3 Parameter Table
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 423
Parameter List
B
H Parameters: Multi-Function Terminals
H parameters assign functions to the multi-function input and output terminals.
H1: Multi-Function Digital Inputs
F6-53
(3C4H)
DeviceNet PPA Setting
Sets the format of the data set from the drive to the DeviceNet master.
Default: 71
Min: 0
Max: 255
F6-54
(3C5H)
DeviceNet Idle Mode Fault
Detection 0: Enabled
1: Disabled, no fault detection
Default: 0
Min: 0
Max: 1
F6-55
(3C6H)
DeviceNet Baud Rate Monitor
Used to verify the baud rate running on the network.
0: 125 kbps
1: 250 kbps
2: 500 kbps
Default: 0
Min: 0
Max: 2
F6-56
(3D7H)
DeviceNet Speed Scaling
Sets the scaling factor for the speed monitor in DeviceNet.
Default: 0
Min: -15
Max: 15
F6-57
(3D8H)
DeviceNet Current Scaling
Sets the scaling factor for the output current monitor in DeviceNet.
Default: 0
Min: -15
Max: 15
F6-58
(3D9H)
DeviceNet Torque Scaling
Sets the scaling factor for the torque monitor in DeviceNet.
Default: 0
Min: -15
Max: 15
F6-59
(3DAH)
DeviceNet Power Scaling
Sets the scaling factor for the power monitor in DeviceNet.
Default: 0
Min: -15
Max: 15
F6-60
(3DBH)
DeviceNet Voltage Scaling
Sets the scaling factor for the voltage monitor in DeviceNet.
Default: 0
Min: -15
Max: 15
F6-61
(3DCH)
DeviceNet Time Scaling
Sets the scaling factor for the time monitor in DeviceNet.
Default: 0
Min: -15
Max: 15
F6-62
(3DDH)
DeviceNet Heartbeat Interval
Sets the heartbeat interval for DeviceNet communications.
Default: 0
Min: 0
Max: 10
F6-63
(3DEH)
DeviceNet Network MAC ID
Used to verify the MAC ID the drive has been assigned.
Default: 0
Min: 0
Max: 63
F6-64 to
F6-71
(3DFH to
3C8H)
Reserved
Reserved for Dynamic I/O Assembly Parameters.
––
<3> Parameter setting value is not reset to the default value when the drive is initialized.
No.(Addr.) Name Description Setting Page
H1-01
(438H)
<31> Value in parenthesis is the default setting when a 3-wire initialization is performed (A1-03 = 3330).
Multi-Function Digital Input
Terminal S1 Function Selection
Assigns a function to the multi-function digital inputs.
Refer to H1 Multi-Function Digital Input Selections on page 424 for a description of setting
values.
Note: Unused terminals should be set to F.
Default: 40 (F)
<31>
Min: 1
Max: 9F
214
H1-02
(439H)
Multi-Function Digital Input
Terminal S2 Function Selection
Default: 41 (F)
<31>
Min: 1
Max: 9F
214
H1-03
(400H)
Multi-Function Digital Input
Terminal S3 Function Selection
Default: 24
Min: 0
Max: 9F
214
H1-04
(401H)
Multi-Function Digital Input
Terminal S4 Function Selection
Default: 14
Min: 0
Max: 9F
214
H1-05
(402H)
Multi-Function Digital Input
Terminal S5 Function Selection
Default: 3(0)
<31>
Min: 0
Max: 9F
214
H1-06
(403H)
Multi-Function Digital Input
Terminal S6 Function Selection
Default: 4(3)
<31>
Min: 0
Max: 9F
214
H1-07
(404H)
Multi-Function Digital Input
Terminal S7 Function Selection
Default: 6(4)
<31>
Min: 0
Max: 9F
214
H1-08
(405H)
Multi-Function Digital Input
Terminal S8 Function Selection
Default: 8
Min: 0
Max: 9F
214
No.(Addr.) Name Description Setting Page
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
