Appendix: E
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 521
Quick Reference Sheet
This section provides tables to keep record of the drive specification, motor specification and
drive settings. Fill in the data after commissioning the application and have them ready when
contacting Yaskawa for technical assistance.
E.1 DRIVE AND MOTOR SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 522
E.2 BASIC PARAMETER SETTINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 523
E.3 USER SETTING TABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 524
