1.4 Drive Models and Enclosure Types
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 31
Receiving
1
1.4 Drive Models and Enclosure Types
Two types of enclosures are offered for A1000 drives.
IP00 enclosure models are designed for installation in an enclosure panel that serves to protect personnel from injury
caused by accidentally touching live parts.
IP20/NEMA Type 1 enclosure models mount to an indoor wall or in an enclosure panel.
Table 1.3 describes drive enclosures and models.
Table 1.3 Drive Models and Enclosure Types
Voltage Class
<1> Removing the top protective cover from a IP20/NEMA Type 1 enclosure drive voids NEMA Type 1 protection but still keeps IP20 conformity.
Enclosure Type
IP20/NEMA Type 1 Enclosure
CIMR-A
<1>
IP00 Enclosure
CIMR-A
Three-Phase
200 V Class
2A0004F
2A0006F
2A0010F
2A0012F
2A0021F
2A0030F
2A0040F
2A0056F
2A0069F
2A0081F
2A0110A
2A0138A
2A0169A
2A0211A
2A0250A
2A0312A
2A0360A
2A0415A
Three-Phase
400 V Class
4A0002F
4A0004F
4A0005F
4A0007F
4A0009F
4A0011F
4A0018F
4A0023F
4A0031F
4A0038F
4A0044F
4A0058A
4A0072A
4A0088A
4A0103A
4A0139A
4A0165A
4A0208A
4A0250A
4A0296A
4A0362A
4A0414A
4A0515A
4A0675A
