YASKAWA A1000 Series

3.11 Connect to a PC
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 81
Electrical Installation
3
3.11 Connect to a PC
This drive is equipped with a USB port (type-B).
The drive can connect to the USB port of a PC using a USB 2.0, AB type cable (sold separately). DriveWizard Plus can
then be used to monitor drive performance and manage parameter settings. Contact Yaskawa for more information on
DriveWizard Plus.
Figure 3.35
Figure 3.31 Connecting to a PC (USB)
PC
(Type-B) (Type-A)
USB Cable
(Type-AB)
YEG
