B.3 Parameter Table
444 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
q: DriveWorksEZ Parameters
r: DriveWorksEZ Connection Parameters
T: Motor Tuning
Enter data into the following parameters to tune the motor and drive for optimal performance
T1: Induction Motor Auto-Tuning
o4-12
(512H)
kWh Monitor Initialization
0: U4-10 and U4-11 monitor data is not reset when the drive is initialized (A1-03).
1: U4-10 and U4-11 monitor data is reset when the drive is initialized (A1-03).
Default: 0
Min: 0
Max: 1
289
o4-13
(528H)
Number of Run Commands
Counter Initialization 0: Number of Run commands counter is not reset when the drive is initialized (A1-03).
1: Number of Run commands counter is reset when the drive is initialized (A1-03).
Default: 0
Min: 0
Max: 1
289
No. (Addr.) Name Description Setting Page
q1-01 to q6-07
(1600H to
1746H)
DriveWorksEZ Parameters
Reserved for DriveWorksEZ
Refer to Help in the
DWEZ software.
289
No. (Addr.) Name Description Setting Page
r1-01 to
r1-40
(1840H to
1867H)
DriveWorksEZ Connection
Parameters 1 to 20 (upper/lower)
DriveWorksEZ Connection Parameters 1 to 20 (upper/lower)
Default: 0
Min: 0
Max: FFFFH
289
No. (Addr.) Name Description Setting Page
T1-00
(700H)
Motor 1 / Motor 2 Selection
1: Motor 1 (sets E1-, E2-)
2: Motor 2 (sets E3-, E4-)
Default: 1
Min: 1
Max: 2
114
T1-01
(701H)
<37>
Auto-Tuning Mode Selection
0: Rotational Auto-Tuning
1: Stationary Auto-Tuning 1
2: Stationary Auto-Tuning for Line-to-Line Resistance
3: Rotational Auto-Tuning for V/f Control (necessary for Energy Savings and Speed Estimation
Speed Search)
4: Stationary Auto-Tuning 2
8: Inertia Tuning (perform Rotational Auto-Tuning prior to Inertia Tuning)
9: ASR Gain Tuning (perform Rotational Auto-Tuning prior to ASR Gain Auto-Tuning)
Default: 0
Min: 0
Max: 4, 8, 9
<10>
114
T1-02
(702H)
Motor Rated Power
Sets the motor rated power as specified on the motor nameplate.
Note: Use the following formula to convert horsepower into kilowatts: kW = HP x 0.746.
Default:
<6>
Min: 0.00 kW
Max: 650.00 kW
115
T1-03
(703H)
<18>
Motor Rated Voltage
Sets the motor rated voltage as specified on the motor nameplate.
Default: 200.0 V
Min: 0.0 V
Max: 255.0 V
115
T1-04
(704H)
Motor Rated Current
Sets the motor rated current as specified on the motor nameplate.
Default:
<6>
Min: 10% of drive rated
current
Max: 200% of drive
rated current
115
T1-05
(705H)
Motor Base Frequency
Sets the rated frequency of the motor as specified on the motor nameplate.
Default: 50.0 Hz
Min: 0.0 Hz
Max: 400.0 Hz
115
T1-06
(706H)
Number of Motor Poles
Sets the number of motor poles as specified on the motor nameplate.
Default: 4
Min: 2
Max: 48
115
T1-07
(707H)
Motor Base Speed
Sets the rated speed of the motor as specified on the motor nameplate.
Default: 1450 r/min
Min: 0 r/min
Max: 24000 r/min
115
No. (Addr.) Name Description Setting Page
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
All Modes
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
OLV/PM AOLV/PM
CLV
V/f w/PG
CLV/PM
V/f OLV
common_
TMonly
