YASKAWA A1000 Series Technical Manual

B.7 Parameters that Change with the Motor Code Selection
472 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
Table B.20 200 V, 1450 r/min Type YASKAWA SST4 Series IPM Motor
No. Name Unit Default Settings
E5-01
Motor Code Selection − 2247 2248 2249 224A 224C 224D 224E
Voltage Class V 400 400 400 400 400 400 400
Rated Power kW 90 110 132 160 200 220 300
Rated Speed r/min 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power kW 90.00 110.00 132.00 160.00 200.00 250.00 300.00
E5-03 Motor Rated Current A 153.1 184.4 229.2 269.8 346.9 421.9 520.8
E5-04Number of Motor Poles –6666666
E5-05 Motor Stator Resistance (r1) Ω 0.019 0.017 0.012 0.008 0.005 0.004 0.002
E5-06 Motor d-Axis Inductance (Ld) mH 1.51 1.43 1.13 0.96 0.65 0.67 0.40
E5-07 Motor q-Axis Inductance (Lq) mH 1.76 1.92 1.54 1.26 0.88 0.74 0.52
E5-09 Motor Induction Voltage Constant 1 (Ke) mVs/rad 538.3 590.9 548.2 603.9 556.8 593.1 495.4
E5-24 Motor Induction Voltage Constant 2 (Ke) mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Maximum Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Minimum Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia
kgm
2
0.55 0.82 0.96 1.60 1.95 2.82 3.70
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.205 0.250 0.244 0.336 0.327 0.379 0.414
n5-02 Motor Acceleration Time s 0.205 0.250 0.244 0.336 0.327 0.379 0.414
n8-49
d-Axis Current for High Efficiency
Control (OLV/PM)
% -8.6 -14.8 -17.5 -12.5 -14.7 -5.1 -16.3
No. Name Unit Default Settings
E5-01
Motor Code Selection − 2302 2303 2305 2306 2308 230A 230B 230D
Voltage Class V 200 200 200 200 200 200 200 200
Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Rated Speed r/min 1450 1450 1450 1450 1450 1450 1450 1450
E5-02 Motor Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03 Motor Rated Current A 1.77 3.33 5.94 9.48 14.17 20.42 27.92 39.6
E5-04Number of Motor Poles –66666666
E5-05 Motor Stator Resistance (r1) Ω 3.154 1.835 0.681 0.308 0.405 0.278 0.180 0.098
E5-06 Motor d-Axis Inductance (Ld) mH 28.46 19.46 10.00 6.88 8.15 5.77 6.32 3.34
E5-07 Motor q-Axis Inductance (Lq) mH 39.29 25.89 15.20 9.25 10.76 8.60 8.80 4.61
E5-09 Motor Induction Voltage Constant 1 (Ke) mVs/rad 268.8 256.9 271.9 260.2 286.8 314.9 300.8 292.3
E5-24 Motor Induction Voltage Constant 2 (Ke) mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-05 Maximum Voltage V 190.0 190.0 190.0 190.0 190.0 190.0 190.0 190.0
E1-06 Base Frequency Hz 72.5 72.5 72.5 72.5 72.5 72.5 72.5 72.5
E1-09 Minimum Output Frequency Hz 3.6 3.6 3.6 3.6 3.6 3.6 3.6 3.6
C5-17 Motor Inertia
kgm
2
0.0016 0.0022 0.0081 0.0133 0.0133 0.017 0.027 0.044
L3-24
Motor Acceleration Time for Inertia
Calculations
s 0.092 0.068 0.125 0.139 0.083 0.070 0.082 0.092
n5-02 Motor Acceleration Time s 0.092 0.068 0.125 0.139 0.083 0.070 0.082 0.092
n8-49
d-Axis Current for High Efficiency
Control (OLV/PM)
% -7.5 -9.4 -13.9 -10.0 -15.0 -17.9 -22.7 -20.5

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
