YASKAWA A1000 Series Technical Manual

2.2 Mechanical Installation
YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual 49
Mechanical Installation
2
Table 2.6 Dimensions for IP00 Enclosure: 200 V Class
Table 2.7 Dimensions for IP00 Enclosure: 400 V Class
Drive Model
CIMR-A2A
Dimensions (mm)
Figure W H D W1 H1 H2 D1 t1 t2 d
Weight
(kg)
0110
1
250 400 258 195 385 7.5 100 2.3 2.3 M6 21
0138 275 450 258 220 435 7.5 100 2.3 2.3 M6 25
0169 325 550 283 260 535 7.5 110 2.3 2.3 M6 37
0211 325 550 283 260 535 7.5 110 2.3 2.3 M6 38
0250 450 705 330 325 680 12.5 130 3.2 3.2 M10 76
0312 450 705 330 325 680 12.5 130 3.2 3.2 M10 80
0360 500 800 350 370 773 13 130 4.5 4.5 M12 98
0415 500 800 350 370 773 13 130 4.5 4.5 M12 99
Drive Model
CIMR-A4A
Dimensions (mm)
Figure W H D W1 H1 H2 D1 t1 t2 d
Weight
(kg)
0058
1
250 400 258 195 385 7.5 100 2.3 2.3 M6 21
0072 275 450 258 220 435 7.5 100 2.3 2.3 M6 25
0088 325 510 258 260 495 7.5 105 2.3 3.2 M6 36
0103 325 510 258 260 495 7.5 105 2.3 3.2 M6 36
0139 325 550 283 260 535 7.5 110 2.3 2.3 M6 41
0165 325 550 283 260 535 7.5 110 2.3 2.3 M6 42
0208 450 705 330 325 680 12.5 130 3.2 3.2 M10 79
0250 500 800 350 370 773 13 130 4.5 4.5 M12 96
0296 500 800 350 370 773 13 130 4.5 4.5 M12 102
0362 500 800 350 370 773 13 130 4.5 4.5 M12 107
0414 2 500 950 370 370 923 13 135 4.5 4.5 M12 125
0515
3
670 1140 370 440 1110 15 150 4.5 4.5 M12 216
0675 670 1140 370 440 1110 15 150 4.5 4.5 M12 221

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
