E.3 User Setting Table
528 YASKAWA ELECTRIC SIEP C710616 27C YASKAWA AC Drive A1000 Technical Manual
n8-45 Speed Feedback Detection Control Gain
n8-47 Pull-In Current Compensation Time Constant
n8-48 Pull-In Current
n8-49 d-Axis Current for High Efficiency Control
n8-51 Acceleration/Deceleration Pull-In Current
n8-54 Voltage Error Compensation Time Constant
n8-55 Load Inertia
n8-57 High Frequency Injection
n8-62 Output Voltage Limit
n8-65
Speed Feedback Detection Control Gain during ov
Suppression
o1-01 Drive Mode Unit Monitor Selection
o1-02 User Monitor Selection After Power Up
o1-03 Digital Operator Display Selection
o1-04 V/f Pattern Display Unit
o1-10 User-Set Display Units Maximum Value
o1-11 User-Set Display Units Decimal Display
o2-01 LO/RE Key Function Selection
o2-02 STOP Key Function Selection
o2-03 User Parameter Default Value
o2-04 Drive Model Selection
o2-05 Frequency Reference Setting Method Selection
o2-06
Operation Selection when Digital Operator is
Disconnected
o2-07 Motor Direction at Power Up when Using Operator
o3-01 Copy Function Selection
o3-02 Copy Allowed Selection
o4-01 Cumulative Operation Time Setting
o4-02 Cumulative Operation Time Selection
o4-03 Cooling Fan Maintenance Operation Time Setting
o4-05 Capacitor Maintenance Setting
o4-07 DC Bus Pre-charge Relay Maintenance Setting
o4-09 IGBT Maintenance Setting
o4-11 U2, U3 Initialize Selection
o4-12 kWh Monitor Initialization
o4-13 Number of Run Commands Counter Initialization
q1-01 to
q6-07
DriveWorksEZ Parameters
r1-01 to
r1-40
DWEZ Connection Parameter 1 to 20 (upper/lower)
T1-00 Motor 1/Motor 2 Selection
T1-01 Auto-Tuning Mode Selection
T1-02 Motor Rated Power
T1-03 Motor Rated Voltage
T1-04 Motor Rated Current
T1-05 Motor Base Frequency
T1-06 Number of Motor Poles
T1-07 Motor Base Speed
T1-08 PG Number of Pulses Per Revolution
T1-09 Motor No-Load Current (Stationary Auto-Tuning)
T1-10 Motor Rated Slip (Stationary Auto-Tuning)
T1-11 Motor Iron Loss
T2-01 PM Motor Auto-Tuning Mode Selection
T2-02 PM Motor Code Selection
T2-03 PM Motor Type
T2-04 PM Motor Rated Power
T2-05 PM Motor Rated Voltage
T2-06 PM Motor Rated Current
T2-07 PM Motor Base Frequency
T2-08 Number of PM Motor Poles
T2-09 PM Motor Base Speed
T2-10 PM Motor Stator Resistance
T2-11 PM Motor d-Axis Inductance
T2-12 PM Motor q-Axis Inductance
T2-13 Induced Voltage Constant Unit Selection
T2-14 PM Motor Induced Voltage Constant
No. Name
User
Setting
T2-15 Pull-In Current Level for PM Motor Tuning
T2-16
PG Number of Pulses Per Revolution for PM Motor
Tuning
T2-17 Encoder Z-Pulse Offset
T3-01 Test Signal Frequency
T3-02 Test Signal Amplitude
T3-03 Motor Inertia
T3-04 System Response Frequency
No. Name
User
Setting

YASKAWA A1000 Series Specifications

General

Series	A1000
Type	AC Drive
Altitude	Up to 1000m without derating
Output Frequency	0-400 Hz
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Communication Options	Modbus, DeviceNet, Profibus, Ethernet/IP
Ambient Temperature	-10 to 50°C
Storage Temperature	-20 to 60°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Horsepower	0.5 to 1000 HP
Power Range	0.4 - 630 kW (varies by voltage and model)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Cooling Method	Fan Cooled
Safety	Safe Torque Off (STO)
