7 System Diagnosis
DX100 7.5 Alarm History
7-18
7.5 Alarm History
7.5.1 Alarm History Window
The alarm history can be confirmed in the alarm history window. There
are five types of alarm history windows: the "MAJOR ALARM" window, the
"MINOR ALARM" window, the "USER ALARM (SYSTEM)" window, the
"USER ALARM (USER)" window, and the "OFF-LINE ALARM" window.
Each window shows the alarm code and the date and time.
1. Select {SYSTEM INFO} under the main menu.
2. Select {ALARM HISTORY}.
The alarm history window appears.
3. Press the page key to change the window, or select "PAGE" to
display the selection window for the alarm windows.
Each time the page key is pressed, the window changes
"MAJOR ALARM""MINOR ALARM""USER
ALARM(SYSTEM)”"USER ALARM(USER)""OFF-LINE
ALARM."
PAGE
GO BACK
PAGE
GO BACK
PAGE
GO BACK
PAGE
GO BACK
