5 Replacing Parts

DX100 5.1 Replacing DX100 Parts

5-23

5.1.6 Interior Circulation Fan

5.1.6.1 Replacing the Interior Circulation Fan

 Replacement Procedures

1. Open the F door.

2. Disconnect plug cables connected to the fan.

(Remove the ground wirings screwed to the fan.)

3. Remove the screws (2 places) fixing the fan.

4. Uninstall the fan from the controller.

5. Install the new fan to the controller.

6. Tighten the screws (2 places) to fix the fan.

7. Connect all the disconnected cables.

8. Close the F door.

NOTE

Turn OFF the power before replacing the fan.
