7 System Diagnosis
DX100 7.3 Input/Output Status
7-7
7.3.5 RIN Input
7.3.5.1 RIN Input Window
1. Select {IN/OUT} under the main menu.
2. Select {RIN}.
– The RIN window appears.
7.3.6 Signal Number Search
A search can be made for a signal number of a universal input, universal
output, specific input, and specific output.
A search for the signal number can be made in the following two ways.
• Direct search on the UNIVERSAL/SPECIFIED INPUT/OUTPUT win-
dow
• Search from the menu
Signal
number
