7.3.6.1 Direct Search on the Universal/Specified Input/Output Window
1. Move the cursor to a signal number in the UNIVERSAL/SPECIFIED
INPUT/OUTPUT window, and press [SELECT].
– Numeric values can now be entered.
2. Enter the signal number to be searched.
– Type the signal number in the number input line.
3. Press [ENTER] to start the search.
– The page where the signal number exists appears.
