10 LED Indicator on Circuit Board
DX100 10.3 7 SEG-LED Indicator
10-3
10.3 7 SEG-LED Indicator
The following tables show the operating statues for JANCD-YIF01/SRDA-
EAXA01/JANCD-YCP02. The operating statuses are indicated by 7 SEG-
LED.
[Normal Indication]
[Error Indication]
Status DX100
YIF01 EAXA01 YCP02
Right after
applying the
power
All 7-SEG indicators light up.
(‘8’, ‘+’, ‘.’ light up.)
During the start-
up process
Counts up from ‘O’ toward ‘d’.
After starting up
normally
‘d’, ‘+’, ‘.’ blink every one second.
Status DX100
YIF01 EAXA01 YCP02
Alarms
occurrence in the
Main CPU and
servo CPU
communication
system
‘d’, ‘+’, ‘.’ blink
every one
second.
The error cause
is indicated by 7
SEG-LED.
(See the
indication spec
1.)
‘d’, ‘+’, ‘.’ blink
every one
second.
Normal alarms
other than alarms
described above
‘d’, ‘+’, ‘.’ blink
every one
second.
Fatal alarms
occurrence
The error cause and the address where the error has
occurred are indicated by 7 SEG-LED.
(See the indication spec
2.)
SUPPLE
-MENT
Indication Spec 1
E.g.)
The cycle: [F] [0] [0] [3] [.] is repeated.
: Error cause
Indication Spec 2
E.g.)
[-] [0] [2] [0] [0] : Error cause
The cycle: [,] [-] [0] [0] [0] [0] [F] [F] [0]
[4] is repeated.: Address where the error occurred
