YASKAWA DX100 - 7.3.3 Specific Input; 7.3.3.1 Specific Input Window; 7.3.3.2 Specific Input Simple Window

7 System Diagnosis
DX100 7.3 Input/Output Status
7-5
7.3.3 Specific Input
7.3.3.1 Specific Input Window
1. Select {IN/OUT} under the main menu.
2. Select {SPECIFIC INPUT}.
– The SPECIFIED INPUT window appears.
7.3.3.2 Specific Input Simple Window
1. Select {IN/OUT} under the main menu.
2. Select {SPECIFIC INPUT}.
– The SPECIFIED INPUT window appears.
3. Select {SIMPLE} from the pull-down menu of {DISPLAY}.
– The SPECIFIED INPUT simple window appears.
