7 System Diagnosis

DX100 7.9 Servo Monitoring

7-25

3. Select {SERVO MONITOR}.

– The SERVO MONITOR window appears.

4. Select {DISPLAY} under the menu.

– The pull-down menu appears.

MONITOR ITEM 1 is the data on the left, and MONITOR ITEM 2 is

the data on the right

5. Select MONITOR ITEM 1 or 2, and view the sub-menu choices by the

cursor key.

– The sub-menu choices appear.
