vi
IM PX8000-02EN
How to Enter Values in Setup Dialog Boxes
1.
Use the keys to display the appropriate setup dialog box.
2.
Use the
jog shuttle or the arrow keys to move the cursor to the setting that you want to set.
3.
Press
SET. The operation varies as indicated below depending on what you are setting.
• A selection menu appears.
• A check box is selected or cleared.
• An item is selected.
• A table of settings is selected.
Displaying a Selection Menu and Selecting an Item
After selecting an item with the jog shuttle,
press SET to confirm it.
Press SET to select rms, mean, dc,
r-mean, or ac.
Press SET to display
the selection menu.
Setting Items in a Table
After moving the cursor to the table, press SET to
select the setting in the table that you want to change.
To exit from the list, press ESC.
Press SET to select the item
How to Clear Setup Dialog Boxes
Press ESC to clear the setup dialog box from the screen.
Key and Jog Shuttle Operations
To Next Page
