6-13
IM 701240-01E
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
App
Index
Triggering
6.8 Setting the Timer Trigger (SIMPLE)
<For a description of this function, refer to page 2-17.>
Procedure
1. Press MENU.
2. Press the TRIGGER soft key.
3. Press the Trigger Cond. Setup soft key.
4. Press the Select soft key to select Simple.
Setting the Trigger Source
5. Press the Source soft key. The trigger source selection menu appears.
6. Use jog shuttle+SELECT to select Time.
Setting the Date/Time and the Interval for Activating Triggers
7. Press the Date/Time soft key. A setup dialog box opens.
8. Use jog shuttle+SELECT to set the Date and Time.
9. When you are done, Use jog shuttle+SELECT to select Set.
10. Press the Time Interval soft key.
11. Turn the jog shuttle to set the ß for activating triggers in the range of 1 min to
24 hours.
