YOKOGAWA SL1400 User Manual

18-10
IM 701240-01E
18.10 Computer Interface
GP-IB
1
Item Specifications
Electrical and mechanical Conforms to IEEE St’d 488-1978 (JIS C 1901-1987)
specifications
Functional specifications SH1, AH1, T5, L4, SR1, RL1, PP0, DC1, DT0, and C0
Protocol Conforms to IEEE St’d 488.2-1992
Code ISO (ASCII) code
Mode Addressable mode
Address Specify a talker/listener address between 0 and 30
Clear remote mode Remote mode can be cleared using the CLEAR TRACE key (except during local lockout).
Serial (RS-232)
1
Item Specifications
Connector type 9-pin D-Sub plug
Electrical characteristics Conforms to the EIA-574 standard (for the 9-pin interface of the EIA-232 (RS-232) standard)
Connection Point-to-point
Transmission mode Full-duplex
Synchronization Start-stop synchronization
Baud rate Select from the following rates.
1200, 2400, 4800, 9600, 19200, 38400, and 57600
If unstable, use 19200 or less.
USB-PC Connection
1
Item Specifications
Connector type USB type B connector (receptacle)
Electrical and mechanical Conforms to USB Rev.1.1
specifications
Data rate 12 Mbps maximum
Number of ports 1
Supported service Remote control
2
PC system supported PCs with standard USB ports running Windows 2000 or Windows XP.
Ethernet (Option)
1
Item Specifications
Number of communication 1
ports
Electrical and mechanical Conforms to IEEE802.3
specifications
Transmission system Ethernet (100BASE-TX/10BASE-T)
Data rate 100 Mbps maximum
Communication protocol TCP/IP
Supported services FTP server, FTP client (network drive), LPR client (network printer), SMTP client (mail
transmission), DHCP, DNS, Web server, and remote control
2
Connector type RJ-45 connector
1 For details on the specifications, see the Communication Interface User’s Manual on the CD-ROM.
2 The SL1400 can be controlled remotely from a host such as a PC. For details, see the Communication Interface User’s Manual on the
CD-ROM. A separate driver is needed to use this function. To download the driver, go to the following website, and then browse to the
download page.
http://www.yokogawa.com/ymi/
