18-8
IM 701240-01E
18.8 USB PERIPHERAL Interface
Item Specifications
Connector type USB type A connector (receptacle)
Electrical and mechanical specifications
Conforms to USB Rev.1.1
Data rate 12 Mbps maximum
Compatible keyboards
1
104 keyboard or 89 keyboard (US) and 109 keyboard or 89 keyboard (Japanese) conforming to
USB HID Class Ver.1.1
Compatible printers
1
ESC/P, ESC/P2, LIPS3, PCL5, and BJ (can be used on models that support the BJC-35V native
commands) that support USB (USB Printer Class Version 1.0)
Compatible mouse
1
Mouse (with wheel) that supports USB HID Class Ver.1.1
Compatible USB mass USB (USB Mass Storage Class) hard disk drive, MO disk drive, and flash memory
storage devices
1
Power supply 5 V, 500 mA
2
(per port)
Number of ports 2
1 For details on compatible USB devices, contact your nearest YOKOGAWA dealer.
2 Devices whose maximum current consumption exceeds 100 mA cannot be connected simultaneously to the two ports.
18.9 Auxiliary I/O Section
Logic Input
Item Specifications
Number of inputs 8 bits × 2
Connector type 26-pin half-pitch connector × 2
Maximum sample rate 10 MS/s
Compatible probes Non-isolated (700986 (8 bits), 702911 (8 bits), 702912 (8 bits)), and
isolated (700987 (8 bits)).
External Trigger Input
Item Specifications
Connector type RCA jack
Input level TTL (0 to 5 V) input
Minimum pulse width 500 ns
Logic Rising edge or falling edge selectable
Trigger delay Within 200 ns + 1 sample
Externally synchronized Possible (by connecting TRIG IN and TRIG OUT on two SL1400s)
operation
Trigger Output (TRIG OUT)*
Item Specifications
Connector type RCA jack, shared with the external sampling clock
Output level CMOS level (0 to 5 V) output
Logic Falls when the trigger is activated, rises after completing acquisition.
Output delay Within 1 µs + 1 sample
Output hold time 200 ns or longer
* This terminal is also used as an external clock input terminal.
To Next Page
