YOKOGAWA SL1400 User Manual

15-46
IM 701240-01E
15.9 Checking the Presence of the Ethernet
Interface and the MAC Address
Procedure
1. Press MENU.
2. Press Next 1/2 soft key.
3. Press the System Config soft key.
4. Press the Overview soft key. The overview screen appears.
5. When Ether:Yes appears for the Option item in the overview screen, this
indicates that the Ethernet interface is installed.
The number indicated to the right is the MAC address.
The MAC number is intentionally blurred in the example below.
Note
• Ether: Yes is displayed only if the Ethernet interface option is installed.
• If XXXXXX_XXX_XXX is displayed for the MAC address, contact your nearest
YOKOGAWA dealer.
Explanation
You can check the presence of the Ethernet interface and the MAC address.
MAC address is a unique address that is pre-assigned to the SL1400.
The Presence of the Ethernet Interface
The presence of the Ethernet interface is displayed under “Ether” on the overview
screen.
• Ether:Yes: The Ethernet interface is installed.
• Ether:No: The Ethernet interface is not installed.
MAC Address
MAC address is a unique address that is pre-assigned to the SL1400. It is necessary for
transmitting data between nodes.
