App-8
IM 701240-01E
$PublicInfo (Common Information)
FormatVersion: Header file version number (common to YOKOGAWA’s header
files)
Model: Model name
Endian: Endian mode when saving data (Big/Ltl)
1
DataFormat: Storage format of the binary waveform data (Trace/Block)
2
GroupNumber: The number of “$Group”s indicated below
TraceTotalNumber: Total number of selected waveforms
DataOffset: Binary file start position
3
$Group1 (Group Information)
TraceNumber: Number of waveforms in this group
BlockNumber: Number of blocks in this group
4
TraceName: Name of each waveform
BlockSize: Number of data points in a single block of each waveform
VResolution: Value of coefficient VResolution of the Y-axis conversion equation
of each waveform
5
VOffset: Value of coefficient VOffset of the Y-axis conversion equation of
each waveform
5
VDataType: Type of binary file waveform data for each waveform
6
VUnit: Unit used on the Y-axis of each waveform (no effect on the data)
VPlusOVerData: Error data when the binary data of each waveform is greater than
or equal to this value
VMinusOVerData: Error data when the binary data of each waveform is less than or
equal to this value
VMaxData: Maximum value of binary data for each waveform
VMinData: Minimum value of binary data for each waveform
HResolution: Value of coefficient HResolution of the X-axis conversion equation
of each waveform
7
HOffset: Value of coefficient HOffset of the X-axis conversion equation of
each waveform
7
HUnit: Unit used on the X-axis of each waveform (no effect on the data)
Date: Date when a trigger is activated
Time: Time when a trigger is activated
For details on 1 to 7, see the next page.
$PrivateInfo (Model-Specific Information)
ModelVersion: Version No. of the instrument
MathBlockNo.: Block No. of block to be computed
DisplayPointNo.: Value indicating the memory position (n
th
point in the memory)
corresponding the left end of the display record length.
PTraceName: Label for each waveform
PUpperScaleData: Scale value of the top edge of the screen
PLowerScaleData: Scale value of the bottom edge of the screen
POffsetName: Offset value
Appendix 5 ASCII Header File Format
