Waveform Display and Information Display
Number of Points Displayed Vertically When Extra Window Is ON
When the extra window is turned ON, the vertical axis size of the waveform display
window is reduced according to the Height setting. The vertical resolution does not
change, but the number of displayed points varies as follows.
Height setting = 8: 384 points Height setting = 7: 400 points
Height setting = 6: 416 points Height setting = 5: 432 points
Height setting = 4: 448 points Height setting = 3: 464 points
Height setting = 2: 480 points Height setting = 1: 496 points
Height setting = 0: 512 points
(When display format is set to Single)
Note
Use of the extra window together with certain zoom formats may cause scale values to overlap
making them difficult to be read.
8.11 Turning the Extra Window ON/OFF
