Screen Image Data Output
Item Specifications
Built-in printer Prints a hard copy of the screen
External printer Outputs the screen image to an external printer via the USB PERIPHERAL terminal or the Ethernet
network.
*
Supports ESC-P, ESC-P2, LIPS3, PCL5, BJ commands, and PostScript (only via the Ethernet
network
*
)
PC card, SCSI, Output data format: PNG, JPEG, BMP, and PostScript
Built-in HDD (option),
Network drive*
* When the Ethernet interface option is installed (to a printer server supporting TCP/IP).
Data Storage
Item Specifications
History memory Automatically holds up to 2000 pages of waveforms (depending on the memory length)
PC card, SCSI, Saves waveform data, setup data, and various data
Built-in HDD (option),
Network drive*
* When the Ethernet interface option is installed.
Acquisition Memory Backup
Item Specifications
Batteries 4 AAA alkaline dry cells (AA/R6) (JIS, IEC model: LR6)
4 nickel hydride rechargeable batteries
Backup time (reference value)
Reference value for A1070EB (LR6JE CPT alkaline battery by Toshiba) × 4 at an ambient
temperature of 23 °C
Approx. 150 hours
Backup function Enable/Disable using the ON/OFF switch
Contents that are Acquisition memory waveform data (history memory data)
backed up
Other Functions
Item Specifications
Initialization Resets settings to the factory default (excluding date/time setting, communication interface settings,
SCSI ID number setting, language setting, time difference from the GMT, and the ON/OFF setting of
the internal hard disk motor)
Auto setup Automatically sets the voltage axis, time axis, trigger level, etc.
Action-on-trigger Outputs screen image data, saves waveform data (binary, ASCII, or floating), activates buzzer
notification, or sends e-mail messages each time a trigger occurs.
Mail transmission function* Sends the SL1400 status periodically to a specified mail address via the Ethernet network. Also
sends information as an action of action-on-trigger.
Calibration Auto calibration and manual calibration available
System settings Set the screen color, date/time, menu/message language, and click sound ON/OFF
Probe compensation Outputs a signal (rectangular signal of approx. 1 V
P-P
and approx. 1 kHz) from the probe
signal output compensation output terminal on the front panel
Overview Shows system specifications
Self-test Memory test, key test, printer test, PC card drive test, internal HDD (optional) test, and SCSI test
Thumbnail Shows thumbnails of the screen images
PROTECT key Disables keys to prevent inadvertent errors in operation.
* When the Ethernet interface option is installed.
