18-9
IM 701240-01E
Specifications
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Video Signal Output (VIDEO OUT (SVGA))
Item Specifications
Connector type 15-pin D-Sub receptacle
Output format Analog RGB output
Output resolution SVGA output 800 × 600 dots/60 Hz Vsync
External Start/Stop
Item Specifications
Connector type Modular jack (RJ-11)
Input TTL (0 to 5 V) or switch input
Start on a low signal and stop on a high signal
Compatible cable Four-wire modular cable for telephone lines (external start/stop cable (YOKOGAWA: 366973))
COMP Output (Rectangular Signal Output for Probe Compensation)
Item Specifications
Output frequency 1 kHz ± 1%
Output amplitude 1 V ± 10%
Probe Power Output (Option)
Item Specifications
Number of output 4
terminals
Output voltage ±12 V 2 outputs (up to a total of 800 mA)
Compatible probes* Current probe (701930 (150 A)) up to 2 probes
Current probe (701931 (500 A)) 1 probe
Current probe (701933 (30 A)) up to 2 probes
* Up to four 700937 current probes can be used, but the 700937 is a discontinued product.
For details on the usage conditions of each probe, contact your nearest YOKOGAWA dealer.
18.9 Auxiliary I/O Section
