iv
IM 701240-01E
Checking the Contents of the Package
Unpack the box and check the contents before operating the instrument. If some of the
contents are not correct, or if any items are missing or damaged, contact the dealer from
whom you purchased them.
SL1400
Check that the model name and suffix code given on the name plate on the left side
panel of the SL1400 match those on your order.
GP-IB
(
IEEE488
)
ON
100-120V/200-240V AC
300VA MAX 50/60Hz
POWER
100BASE-TX
VIDEO OUT
(
SVGA
)
SERIAL
(
RS-232
)
USB
USB PERIPHERAL
LOGIC B
TRIG OUT/
EXT CLK IN
LINK
ACT
SCSI
LOGIC A
OFF
START/
STOP
TRIG IN
MODEL
NO.
SUFFIX
Made in Japan
MODEL
NO.
SUFFIX
Made in Japan
MODEL Suffix Code Description
701240 (SL1400) The input module is not included with the instrument.
See the next page for information on the input module.
Power cord
1
-D UL/CSA Standard power cord (Part No.: A1006WD)
Maximum rated voltage: 125 V
-F VDE Standard power cord (Part No.: A1009WD)
Maximum rated voltage: 250 V
-Q BS Standard power cord (Part No.: A1054WD)
Maximum rated voltage: 250 V
-R AS Standard power cord (Part No.: A1024WD)
Maximum rated voltage: 250 V
-H GB Standard power cord (Part No.: A1064WD)
Maximum rated voltage: 250 V
Default language -HE English
-HJ Japanese
-HC Chinese
-HK Korean
-HG German
-HF French
-HL Italian
-HP Spanish
Built-in media drive -J0 No built-in media drive
-J3 PC card drive
Options /C8 Internal hard disk 40 GB (FAT32)
/C10 Ethernet interface
/P4 Four probe power outputs
1 Make sure that the attached power cord meets the designated standards of the country and
area that you are using it in.
NO. (Instrument Number)
When contacting the dealer from which you purchased the instrument, please give them
this number.
To Next Page
