vi
IM 701240-01E
Optional Accessories (Sold Separately)
The optional accessories below are available for purchase separately. Check that all
contents are present and undamaged. For information and ordering, contact your
nearest YOKOGAWA dealer.
Name Model Safety standard
1
Description
Isolated probe 700929 1000 Vrms CAT II 10:1 safety probe, for the 701250/701251
Current probe 701930 300 Vrms CAT III DC to 10 MHz bandwidth. Used by connecting to the
probe power terminal
701931 300 Vrms CAT III DC to 2 MHz bandwidth. Used by connecting to the probe
power terminal
701933 300 Vrms DC to 50 MHz bandwidth. Used by connecting to the
probe power terminal
10:1 passive probe 701940 – For non-isolated input on the 701255: 600 V or less
For isolated input other than above: 42 V or less
Differential probe 700924 1000 Vrms CAT III
2
Switchable between 1000:1 and 100:1
Measurable voltage: 1400 Vpeak (1000 Vrms)
1:1 BNC safety adapter lead 701901 1000 Vrms CATII For use with the 701250 and 701251. Used with the
following items (which are sold separately): the 701954,
701959, 758922, 758929, or 758921.
Measurement lead 758933 1000 Vrms CAT III 1 m in length; for use with the 701267. Used with the
following items (which are sold separately): the 701954,
701959, 758922, 758929, or 758921.
Alligator clip (dolphin type) 701954 1000 Vrms CAT III 2 pieces in one set (red/black)
Safety mini-clip (hook type) 701959 1000 Vrms CAT II 2 pieces in one set (red/black)
Alligator clip adapter 758922 300 Vrms CAT II 2 pieces in one set
Alligator clip adapter 758929 1000 Vrms CAT II 2 pieces in one set
Fork terminal adapter 758921 1000 Vrms CAT II 2 pieces in one set (red/black), for 4-mm screws
Cables
3
366926 – For measuring low voltage of less than or equal to 42 V
Banana-alligator clip cable 366961 – For measuring low voltage of less than or equal to 42 V
for the 701261, 701262, or 701265
High-speed logic probe 700986 – 42 V or less, 8-bit non-isolated/response speed of 1 µs
Isolated logic probe 700987 250 Vrms CAT II 8 bits, each channel isolated, response speed of 20 ms
(for AC)
Measurement lead for isolated 758917 1000 Vrms CAT II 2 pieces in one set, used with the 758922 or 758929
logic adapter sold separately
Logic probe 702911 – 35 V or less, 8-bit non-isolated, response speed 3 µs,
(lead length: 1 m)
702912 – 35 V or less, 8-bit non-isolated, response speed 3 µs,
(lead length: 3 m)
Conversion adapter 366928 – 42 V or less, BNC (jack) to RCA (plug)
Modular cable 366973 – For external start/stop
Safety BNC cable (1 m) 701902 1000 Vrms CAT II –
Safety BNC cable (2 m) 701903 1000 Vrms CAT II –
Safety BNC-to-banana adapter 758924 500 Vrms CAT II For the 701250, 701251, and 701255
Bridge head 701955 – NDIS, bridge resistance: 120 Ω
701956 – NDIS, bridge resistance: 350 W
701957 – DSUB, bridge resistance: 120 W, shunt-cal support
701958 – DSUB, bridge resistance: 350 W, shunt-cal support
Soft carrying case 701967 – With three pockets
Sold in units of 1 piece.
1 The actual voltage that can be used is the lower voltage of the specifications of the SL1400 and the cable.
2 Be sure to connect the GND lead provided with the 700924 to the functional ground terminal of the SL1400. A measurement
of 1400 Vpeak is possible by connecting the GND lead to the SL1400.
3 Use cables (366926) that YOKOGAWA has been shipping since February 4, 1998. Cables (366926) shipped before this
date cannot be used in combination with the SL1400 input modules.
Checking the Contents of the Package
To Next Page
