5: Replacement Procedures

Procedures

P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 171

Step 3. Apply Super Lube Synthetic Multi-Purpose Grease to the inside surface (arrow

below) all the way around.

Step 4. Slide the Printhead Lift Cam into the Frame.
