Zebra ZXP Series 3 Service Manual

206 Zebra ZXP Series 3 Card Printer Service Manual P1061317-002
C: Accessing a Network Printer via a Web Browser
Procedure
Step 1. Start your Web Browser.
Step 2. In the browser address bar, enter the IP address of the ZXP Series 3 Card Printer
connected to the local Ethernet network. You can get the IP address by checking the
printer configuration; see Viewing Printer Information on page 20 for details.
Step 3. When the Device Status screen appears, click on the Network Settings tab
(arrow below).
Step 4. When the Windows Security dialog box appears, type the User name (admin) and
Password (1234); and click on the OK button.
Important • For the next step, the User name = admin; and the Password = 1234.

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
