Zebra ZXP Series 3 Service Manual

G: Half-Panel Ribbon Operation
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 235
Step 4. Enter the half-panel command.
a. From the Tools dialog box, type the command in the “Command to send to
printer” field to position the print window on the card; e.g., HALF 0.
b. Click the Execute button. If successful the printer will respond with <ACK> in
the Printer Status field directly under the “Command to send to printer” field.
c. Click the Close button to close the Tools dialog box.
d. Click the OK button to exit the Printer Properties.
Step 5. From your card printing application, print your card(s).
Type the
command
here ...
... then
click the
Execute
button.
HALF 0

Zebra ZXP Series 3 Specifications

General

Color	No
Card size	54 x 86 mm
Card types	Magnetic stripe (ISO 7811), PVC, PVC Composite, Smart card
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 DPI
Print speed (color)	180 card/h
Print speed (monochrome)	750 card/h
Printing media thickness	762 µm
Duplex print speed (color)	140 card/h
Display	LCD
Certification	FCC, CE, UL, CUL
Product color	Grey, White
Internal memory	32 MB
Built-in barcodes	EAN13, EAN8, Interleaved 2/5, PDF417, UPC-A
Total input capacity	100 sheets
Display number of characters	16
Compatible operating systems	Windows
Storage temperature (T-T)	-5 - 70 °C
Operating temperature (T-T)	15 - 30 °C
Storage relative humidity (H-H)	20 - 70 %
Operating relative humidity (H-H)	20 - 65 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB
Optional connectivity	Ethernet, USB 2.0

Weight and Dimensions

Weight	5530 g
Dimensions (WxDxH)	201 x 368 x 309 mm
