H: Upgrade Kit Instructions
Contact Station
P1061317-002 Zebra ZXP Series 3 Card Printer Service Manual 287
Remove the Ethernet Assembly
Step 1. With a TORX T10 driver, remove the four screws holding the Ethernet Assembly
(arrows below) in place. When reinstalling the Ethernet Assembly, tighten the
screws to 5.0 in-lb.
Step 2. Remove the Ethernet Assembly.
NOTE • This section only applies to Printers with the Ethernet Option.
