Parameters 199
03.09 ACC COMP TORQ
Shows the output of the acceleration compensation
torque.
0.0%/ Real
-1600.0...
1600.0%
Acceleration compensation torque in percent. 10 = 1%/ -
05
05 LIFT CTRL
VALUES
Signals for monitoring the lift control functions.
05.01 LIFT SW
Lift control status word. - / Pb
No. Bit/Name/Value/
Range
Description Def/Type
FbEq
(16b/32b)
Bit Name Value Information
0 SPEED1 ACT 1 Speed1 (parameter 80.10) is the current speed
reference used by the lift.
0 Speed1 (parameter 80.10) is not the current speed
reference used by the lift.
1 LEVELING ACT 1 Leveling speed (parameter 80.11) is the current
speed reference used by the lift.
0 Leveling speed (parameter 80.11) is not the current
speed reference used by the lift.
2 RELEVELING
ACT
1 Releveling speed (parameter 80.13) is the current
speed reference used by the lift.
0 Releveling speed (parameter 80.13) is not the
current speed reference used by the lift.
3MEDIUM SPD
ACT
1 Medium speed (parameter 80.14) is the current
speed reference used by the lift.
0 Medium speed (parameter 80.14) is not the current
speed reference used by the lift.
4 NOMINAL SPD
ACT
1 Nominal speed (parameter 72.01) is the current
speed reference used by the lift.
0 Nominal speed (parameter 72.01) is not the current
speed reference used by the lift.
5
INSPECT SPD
ACT
1 Inspection speed (parameter 80.15) is the current speed
reference used by the lift.
0 Inspection speed (parameter 80.15) is not the current speed
reference used by the lift.
6
BRK SLIP ALARM 1 Brake is slipping while the motor is not running.
0 Brake is not slipping (No BRAKE SLIP alarm active).
7 EVAC SPD ACT 1 Evacuation speed (parameter 80.16) is the current speed
reference used by the lift.
0 Evacuation speed (parameter 80.16) is not the current speed
reference used by the lift.
(continued)
