308 Fault tracing
0058
FIELDBUS PAR
ERROR
The drive does not have a
functionality requested by
PLC, or the requested
functionality has not been
activated.
Check PLC programming.
Check fieldbus parameter settings.
See parameter group 50
FIELDBUS on page 251.
0061
SPEED
FEEDBACK
No speed feedback is
received.
Check the settings of the
parameters in group 22 SPEED
FEEDBACK.
Check encoder installation. See the
description of fault 0039
(ENCODER1) for more information.
0067
FPGA ERROR1 Drive internal fault Contact your local ABB
representative.
0068
FPGA ERROR2 Drive internal fault Contact your local ABB
representative.
0069
ADC ERROR Drive internal fault Contact your local ABB
representative.
0077
BRAKE NOT
CLOSED MON2
Programmable
fault: 35.08 BRAKE
FAULT FUNC
Mechanical brake control
fault. The fault is activated
if brake monitoring is not
as expected during brake
closing.
Check the mechanical brake
connection.
Check mechanical brake settings,
parameters 35.01…35.08.
To determine whether the problem
is with the monitoring signal or
brake: Check if the brake is closed
or open.
0078
BRAKE NOT
OPEN MON2
Programmable
fault: 35.08 BRAKE
FAULT FUNC
Mechanical brake control
fault. The fault is activated
if brake monitoring is not
as expected during brake
opening.
Check the mechanical brake
connection.
Check mechanical brake settings,
parameters 35.01…35.08.
To determine whether the problem
is with the monitoring signal or
brake: Check if the brake is closed
or open.
0201
T2 OVERLOAD Firmware time level 2
overload
Note: This fault cannot be
reset.
Contact your local ABB
representative.
0201
T3 OVERLOAD Firmware time level 3
overload
Note: This fault cannot be
reset.
Contact your local ABB
representative.
0203
T4 OVERLOAD Firmware time level 4
overload
Note: This fault cannot be
reset.
Contact your local ABB
representative.
Code Fault Cause What to do
