Fault tracing 307
0045
FIELDBUS COMM
Programmable
fault: 50.02 COMM
LOSS FUNC
Cyclical communication
between the drive and
fieldbus adapter module or
between PLC and fieldbus
adapter module is lost.
Check the status of fieldbus
communication. See the
appropriate fieldbus adapter
module User’s manual.
Check fieldbus parameter settings.
See parameter group 50
FIELDBUS on page 251.
Check cable connections.
Check if the communication master
can communicate.
0046
FB MAPPING FILE Drive internal fault Contact your local ABB
representative.
0047
MOTOR
OVERTEMP
Programmable
fault: 46.07 MOT
TEMP PROT
Measured motor
temperature has exceeded
the fault limit defined with
parameter 46.10 MOT
TEMP FLT LIM.
Check that the actual number of
sensors corresponds to the value
set with parameter 46.08 MOT
TEMP SOURCE.
Check motor ratings and load.
Let the motor cool down. Ensure
proper motor cooling: Check the
cooling fan, clean cooling surfaces,
etc.
Check the value of the fault limit.
0049
AI SUPERVISION
Programmable
fault: 13.12 AI
SUPERVISION
Analogue input AI1 or AI2
signal has reached the limit
defined with parameter
13.13 AI SUPERVIS ACT.
Check the analogue input AI1/2
source and connections.
Check analogue input AI1/2
minimum and maximum limit
settings, parameters 13.02 and
13.03 / 13.07 and 13.08.
0050
ENCODER CABLE
Programmable
fault: 90.05 ENC
CABLE FAULT
Encoder cable fault
detected.
Check the cable between FEN-xx
interface and encoder. After any
modifications in cabling, re-
configure the interface by switching
the drive power off and on, or by
activating parameter 90.06 ENC
PAR REFRESH.
0055
TECH LIB Resettable fault generated
by a technology library.
Refer to the documentation of the
technology library.
0056
TECH LIB
CRITICAL
Permanent fault generated
by a technology library.
Refer to the documentation of the
technology library.
0057
FORCED TRIP Generic Drive
Communication Profile trip
command.
Check PLC status.
Code Fault Cause What to do
