A96G166/A96A166/A96S166 User’s manual 14. I2C

137

I2CSAR (I2C Slave Address Register): E9H

SLA7

SLA6

SLA5

SLA4

SLA3

SLA2

SLA1

GCALLEN

R/W

Initial value: 00H

SLA[7:1]

These bits configure the slave address of this I2C module when

I2C operates in slave mode.

GCALLEN

This bit decides whether I2C allows general call address or not

when I2C operates in slave mode.

Ignore general call address

Allow general call address

I2CSAR1 (I2C Slave Address Register 1): EAH

SLA7

SLA6

SLA5

SLA4

SLA3

SLA2

SLA1

GCALLEN

R/W

Initial value: 00H

SLA[7:1]

These bits configure the slave address of this I2C module when

I2C operates in slave mode.

GCALLEN

This bit decides whether I2C allows general call address or not

when I2C operates in slave mode.

Ignore general call address

Allow general call address
