A96G166/A96A166/A96S166 User’s manual 15. USART 0/1
157
UnSTAT (USART Status Register) CFH/F7H
7
6
5
4
3
2
1
0
UDRE
TXC
RXC
WAKE
SOFTRST
DOR
FE
PE
R/W
R/W
R/W
R/W
R/W
R
R
R
Initial value: 80
H
UDRE
The UDRE flag indicates if the transmit buffer (UDATA) is ready to
be loaded with new data. If UDRE is ‘1’, it means the transmit buffer
is empty and can hold one or two new data. This flag can generate
an UDRE interrupt. Writing ‘0’ to this bit position will clear UDRE
flag.
0
Transmit buffer is not empty.
1
Transmit buffer is empty.
TXC
This flag is set when the entire frame in the transmit shift register
has been shifted out and there is no new data currently present in
the transmit buffer. This flag is automatically cleared when the
interrupt service routine of a TXC interrupt is executed. It is also
cleared by writing ‘0’ to this bit position. This flag can generate a
TXC interrupt.
0
Transmission is ongoing.
1
Transmit buffer is empty and the data in transmit shift
register are shifted out completely.
RXC
This flag is set when there are unread data in the receive buffer and
cleared when all the data in the receive buffer are read. The RXC
flag can be used to generate a RXC interrupt.
0
There is no data unread in the receive buffer
1
There are more than 1 data in the receive buffer
WAKE
This flag is set when the RX pin is detected low while the CPU is in
stop mode. This flag can be used to generate a WAKE interrupt.
This bit is set only when in asynchronous mode of operation.
NOTE
0
No WAKE interrupt is generated.
1
WAKE interrupt is generated.
SOFTRST
This is an internal reset and only has effect on USART. Writing ‘1’
to this bit initializes the internal logic of USART and is auto cleared.
0
No operation
1
Reset USART
DOR
This bit is set if a Data OverRun occurs. While this bit is set, the
incoming data frame is ignored. This flag is valid until the receive
buffer is read.
0
No Data OverRun
1
Data OverRun detected
FE
This bit is set if the first stop bit of next character in the receive
buffer is detected as ‘0’. This bit is valid until the receive buffer is
read.
0
No Frame Error
1
Frame Error detected
PE
This bit is set if the next character in the receive buffer has a Parity
Error when received while Parity Checking is enabled. This bit is
valid until the receive buffer is read.
0
No Parity Error
1
Parity Error detected
NOTE: When the WAKE function of USART is used as a release source from STOP mode, it is required to clear
this bit in the RX interrupt service routine. Else the device will not wake-up from STOP mode again by the
change of RX pin.
