Accu-Chek Inform II User Manual

General Product Information • 12
173
08424705001 (01) 2017-04 USA • Accu-Chek Inform II Operator’s Manual Version 6
* Not applicable to Accu-Chek Inform II Base Unit Light
** EAN 13 barcodes are not recommended for identification of operators and patients
Specification Meter Base unit Power supply unit
Battery voltage/type 3.7 volt rechargeable
(lithium technology)
N/A N/A
Input voltage +7.5 V DC Base Unit: +12 V DC
Base Unit Light: +7.5 V DC
100 to 240 V AC
Input frequency DC DC 50 to 60 Hz
Input current 1.7 A (max) Base Unit: 1.25 A (max)
Base Unit Light: 1.7 A (max)
350 to 150 mA
Battery capacity 30 (subsequent)
measurements possible
after 90 min of charging
1
N/A N/A
Interfaces Charging contacts
IR port
Barcode scanner
WLAN
(Channel 1-11 only)
Charging contacts
IR port
RJ45 Ethernet (Base Unit)
RJ25 (Base Unit Light)
USB type B *
DC connector
Replaceable AC
input contacts
Data transfer rate WLAN: up to 54 Mbps IR: 9.6K - 115K bps *
Ethernet: 10/100 Mbps
(auto-negotiate)
full-duplex *
USB: 12 Mbps *
N/A
Supported barcodes Code 128, Code 39,
Code 93, EAN 13 **,
Interleaved 2 of 5 (with or
without checksum),
Codabar, GS1 DataBar Lim-
ited, Aztec, QR Code, Data-
Matrix, PDF417
N/A N/A
1. A fully charged battery pack will provide sufficient power for at least 100 tests within 5 hours including
wireless communication (WLAN, if available and enabled). If wireless communication is enabled, a
fully charged battery pack will deplete within less than a day even without performing tests. Roche
recommends storing meters in the base unit.

Accu-Chek Inform II Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	1000 test results
Display	LCD
Measurement Range	10 to 600 mg/dL
Connectivity	Infrared
Sample Type	Capillary whole blood
Operating Temperature	16 to 32°C (61 to 90°F)
Relative Humidity	10 to 90% non-condensing
