Accu-Chek Inform II User Manual

174
08424705001 (01) 2017-04 USA • Accu-Chek Inform II Operator’s Manual Version 6
The performance of this system has not been evaluated in the critically ill. For more information
about the Accu-Chek Inform II test strip, refer to the package insert for instructions for use,
performance characteristics, and limitations of the system.
Specification Accessory box Code key reader Base unit hub
Height 3.35 in / 85 mm 0.72 in / 18.4 mm 1.38 in / 35 mm
Width 11.02 in / 280 mm 1.37 in / 34.8 mm 6.65 in / 169 mm
Length 10.71 in / 272 mm 2.78 in / 70.7 mm 5 in / 127 mm
Weight 1100 g 28 g 470 g
Operating temperature N/A 37 to 122 °F
3 to 50 °C
37 to 122 °F
3 to 50 °C
Storage temperature
(short-term)
-13 to 158 °F
-25 to 70 °C
37 to 122 °F
3 to 50 °C
-13 to 158 °F
-25 to 70 °C
Relative humidity
(short-term storage)
< 93% < 93% < 93%
Battery voltage/type N/A Not replaceable N/A
Interfaces N/A IR port
Code key socket
LED (red, green, blue)
Input voltage N/A N/A +12 V DC
Input current N/A N/A 2.0 A
Specification Accu-Chek Inform II Test Strip
System measurement range 10-600 mg/dL
Hematocrit 10-65 %
Altitude up to 10,000 feet
Measurement temperature 61 to 95 °F (16 to 35 °C)
Operating humidity 10-80 %
Acceptable samples: Whole Blood: capillary, venous, arterial, and neonate
heelstick
Sample size 0.6 μL

Accu-Chek Inform II Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	1000 test results
Display	LCD
Measurement Range	10 to 600 mg/dL
Connectivity	Infrared
Sample Type	Capillary whole blood
Operating Temperature	16 to 32°C (61 to 90°F)
Relative Humidity	10 to 90% non-condensing
