General Information
Subject to Export Control, see Cover Page for details.
1-2
Optional Test Systems and Functions
The 3900 Series provides various optional test systems and functions that allow users to configure the
Test Set to meet a variety of testing requirements. Optional systems currently available for the 3900
Series are listed below. Refer to Appendix F, Optional Test Systems and Functions for detailed
description of these options.
Audio Analyzer
AutoTest II Systems:
● AutoTest II Analog
● AutoTest II P25
● AutoTest II HPD
DMM (Digital Multimeter)
HPD® Testing Option
HPD® Advanced Analysis Package
IQ Gen Option
P25 Conventional
TETRA Systems:
● TETRA BS
● TETRA BS T1
● TETRA DM
● TETRA Economy Mode
● TETRA MS
● TETRA MS T1
Vocoder Option
Site Monitoring (Sensitivity Search)
Remote and Automatic Control
IEEE Std 488
The 3900 may be operated remotely via an interface conforming to IEEE Std 488.1-1987. This
standard defines the electrical, mechanical and low-level protocol characteristics of the bus
structure, the GPIB (General Purpose Interface Bus).
Several SCPI features have been implemented in the 3900 to facilitate system integration.
These features include the extended status reporting structure, the error numbering scheme, the
command mnemonic derivation rules (long and short form) and many of the frequently used
commands. Many of the SCPI features included in the 3900 are not defined by the SCPI
standard, therefore, the 3900 is not fully compliant with SCPI (Standard Commands for
Programmable Instruments) requirements. Refer to SCPI 1997 for details.
Refer to Chapter 3, section titled Remote Tile
for information on configuring the Test Set for
Remote Operation.
Refer to the 3900 Series Remote Programming Manual for list of valid remote commands.
