General Information
Subject to Export Control, see Cover Page for details.
1-3
Test Setup
The 3900 is suitable for performing radio system measurements on high performance equipment in
research and development environments as well as in production and maintenance facilities. Refer to
Chapter 2, Installation Requirements, for power requirements and control system information and
peripheral equipment connections. The picture below shows an example of a typical test setup.
Digital Radio System
Fig. 1-2 Basic Test Setup
RF Device
Under Test
RF Output
RF Input
Modulated RF
Test Signal
Modulated RF
Test Signal
Connect to the T/R or ANT
Connector depending on the
power of the RF Output of
the device under test.
To Next Page
