AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-25
Channel / Spectrum Analyzer Test
This set of tests verifies functionality of the Channel Analyzer and Spectrum Analyzer.
Do not include brackets ( [ ] ) in command script.
Time-out for the following Test Commands is 80 seconds.
Test Commands
test_analyzer_marker1
Tests to verify Marker 1 is within specified limits.
test_analyzer_marker2
Tests to verify Marker 2 is within specified limits.
Set Commands
set_analyzer_tos [ scale in dB ]
Sets Analyzer Top of Scale value.
Format: Decimal value in dB
set_analyzer_vdiv [ state 0 to 3]
Sets scaling dB/div.
Valid states are:
0 = 1 dB/div
1 = 2 dB/div
2 = 5 dB/div
3 = 10 dB/div
set_analyzer_horiz_mode [ state 0 to 2 ]
Sets horizontal mode of analyzer.
Valid states are:
0 = Center - Span
1 = Start - Stop
2 = Zero - Span
set_analyzer_center_freq [ value in MHz ]
Sets analyzer center frequency.
Format: Decimal value in MHz
set_analyzer_span [ value in MHz ]
Sets analyzer span in MHz
Format: Decimal value in MHz
set_analyzer_rbw [ value in Hz ]
Sets analyzer resolution bandwidth.
Format: Whole number in Hz
set_analyzer_videobw [ value in HZ ]
Sets analyzer video bandwidth.
Format: Whole number in Hz
set_analyzer_sweep [ value in ms ]
Sets analyzer sweep time.
Format: Whole number in ms
