3900 Platform Specifications
Subject to Export Control, see Cover Page for details.
B-17
RF Spectrum Analyzer (cont)
Video Bandwidth
10 Hz to 1 MHz in a 1, 3, 10 sequence, NONE
Sweep
Frequency Sweep Time
100 mS to 100 S in a 1, 2, 5 sequence
Zero Span Sweep Time
50 mS to 100 S in a 1, 2, 5 sequence
Sweep Trigger Source
Internal and External
Trigger Modes
Continuous (Repeat), Single (Single-shot)
Function/Feature
Display Modes
Live, Average, Max Hold
Averages
1 to 100
Markers
Track
Frequencies (or time) and amplitudes
Number of Markers
2
Marker Functions
Marker to Peak
Marker to Next Right/Left
Marker to Minimum
Marker to Ref Level
Marker to Center Frequency
Marker sets Span
Marker sets Vertical Scale (Zero Span only)
Tracking Generator (Option)
Tracking Generator Output
(measured at Center frequency)
Refer to RF Signal Generator section for:
Frequency Range and Accuracy
Output Level Range, Resolution, Accuracy and Spectral Purity
Span and Sweep Time
Same as Spectrum Analyzer
Tracking Generator Controls
Output Port Selection, RF Level, Reference Call
