Test Set Operation
Subject to Export Control, see Cover Page for details.
3-10
Rear Panel Controls and Connectors
Fig. 3-5 3900 Series Rear Panel Connectors
Numerical references are shown in parenthesis (nn).
Rear Panel Connectors
Numerical
Reference
Rear Panel Connectors Page
30 AC Power Connector 3 - 11
31 AC Power Fuse 3 - 11
32 AC Power Supply Switch 3 - 11
33 Rear Cooling Outlets 3 - 11
34 IF Output Signal Connector 3 - 11
35 Ext Ref I/O External Interface 3 - 11
36 Audio Input Connectors 3 - 11
37 External Trigger Source Input 3 - 11
38 Audio Output Connector 3 - 11
39 Sync Signal I/O Connector 3 - 12
40 Auxiliary IF Input Connector 3 - 12
41 GPIB/IEEE-488 Interface Connector 3 - 12
42 Standard USB Client Connector 3 - 12
43 PS/2 Mouse Interface Connector 3 - 12
44 Keyboard Interface Connector 3 - 12
45 USB Connector 3 - 12
46 Ethernet Connector 3 - 12
47 VGA Monitor Output Connector 3 - 13
48 RS-232 Serial Connector 3 - 13
49 Parallel Printer Output Connector 3 - 13
30
31
32
33
34
35
37
38
39
40
41
42
43
44
45
46
47
48
49
36
