E-1
Appendix E
Common Features Quick Reference Guide
The chart below identifies the Tile location or soft key used to access common settings and
functions.
Setting System Field / Function Location
AGC Analog Duplex Analyzers Tile (Level field)
HPD® RF Control Settings Tile
P25 N/A
TETRA Systems RF Settings Tile or Control Tile
Calling Party SSI TETRA Systems Call Types Configuration Tile
Messages Configuration Tile
Calling Party ESN TETRA Systems Call Types Configuration Tile
External Source Analog Duplex Generators Tile
P25 Audio Configuration Tile
Factory Defaults (Restore) All Systems Store/Recall Utility Tile
Fan Control All Systems Operational Status Utility Tile
Frequency Reference All Systems Frequency Reference Utility Tile
Impedance Analog Duplex Analyzers Tile
Generators Tile
HPD® N/A
P25 N/A
TETRA Systems Audio Test Tile
Loudspeaker Analog Duplex AF Measurements Configuration Tile
Analyzers Tile
Modulations Measurements
Configuration Tile
Ports Configuration Tile
HPD® N/A
P25 Audio Configuration Tile
TETRA Systems Audio Test Tile
Pre-Amp All Systems Channel Analyzer
Spectrum Analyzer
Analog Duplex Ports Configuration Tile
HPD® RF Control Settings Tile
P25 N/A
TETRA Systems RF Settings Tile or Control Tile
MIC Phantom Power Analog Duplex Only AF Measurements Configuration Tile
Mod Gen Configuration Tile
Ports Configuration Tile
