AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-30
Oscilloscope Test
This set of tests verifies functionality of the Oscilloscope.
Do not include brackets ( [ ] ) in command script.
Test Commands
test_scope_marker1
Tests to verify Marker 1 is within specified limits.
test_scope_marker2
Tests to verify Marker 2 is within specified limits.
Set Commands
set_scope_traceasource [ state 0 to 6 ]
Selects Trace A source
Valid states are:
0 = Off
1 = Channel1
2 = Channel2
3 = Audio
4 = Audio Filtered
5 = Demod,
6 = Demod Filtered.
set_scope_tracealevel [ state 0 to 12 ]
Trace A source <5 [ state 0 to 12 ]
0 = 2 mV 7 = 500 mV
1 = 5 mV 8 = 1 V
2 = 10 mV 9 = 2 V
3 = 20 mV 10 = 5 V
4 = 50 mV 11 = 10 V
5 = 100 mV 12 = 20 V
6 = 200 mV
FM (Demod/Demod filtered): [ state 0 to 6 ]
0 = 500 Hz
1 = 1 kHz
2 = 2 kHz
3 = 5 kHz
4 = 10 kHz
5 = 20 kHz
6 = 50 kHz
AM (Demod/Demod filtered): [ state 0 to 3 ]
0 = 5%
1 = 10%
2 = 20%
3 = 50%
