AutoTest Sytem Operation
Subject to Export Control, see Cover Page for details.
5-29
Set Commands (cont)
set_analyzer_marker2topeak
Moves marker to peak point on trace.
Must insert a 1 s wait command when this command follows the
set_analyzer_marker1enable command or set_analyzer_marker1position command.
set_analyzer_marker2tomin
Moves marker to lowest point on trace.
set_analyzer_marker2setscf
Sets Center Frequency to frequency at defined marker position.
set_analyzer_marker2setsref
Sets Reference Level to level at defined marker position.
set_analyzer_marker2setsright
Moves marker right to next peak on trace.
set_analyzer_marker2setsleft
Moves marker to left to next peak on trace.
set_analyzer_marker2_ulimit [ limit dBm ]
Sets analyzer marker upper limit.
Format: Decimal limit value in dBm
set_analyzer_marker2_ulen [ state 0/1 ]
Enables/Disables the upper limit check on Marker 2.
Valid states are:
0 = Disabled
1 = Enabled
set_analyzer_marker2_llimit [ limit dBm ]
Sets analyzer marker lower limit.
Format: Decimal limit value in dBm
set_analyzer_marker2_llen [ state 0/1 ]
Enables/Disables the lower limit check on Marker 2.
Valid states are:
0 = Disabled
1 = Enabled
set_analyzer_marker_lockmode [ state 0/1 ]
Lock/Unlock markers when both are enabled.
Valid states are:
0 = Unlocked
1 = Locked
