Aeroflex 3901 - AF Limits con Figur Ation Tile; DMM L Imits C Onf Igura Tion Tile

Analog Duplex System
Subject to Export Control, see Cover Page for details.
8-15
AF Limits Configuration Tile
The AF Limits Configuration Tile sets Pass/Fail limit parameters for AF Measurements. When a
filtered output option is selected, the filter type is selected from the Psoph filter drop-down menu
on the AF Measurements Configuration Tile
or Modulation Measurements Configuration Tile.
Fig. 8-12 Analog Duplex - AF Limits Configuration Tile
DMM Limits Configuration Tile
The DMM Limits Configuration Tile sets Pass/Fail limit parameters for resistance measurements and
AC and DC current and voltage measurements. This Tile is only available when the DMM Option
(390XOPT053) is installed in the Test Set.
Fig. 8-13 Analog Duplex - DMM Limits Configuration Tile
